PS-6000.5 | 6,000 WATT 5-CHANNEL CAR AMPLIFIER

Was: $1,499.95
Now: $999.95
1 review Write a Review
Lease for as low as /week
Learn More
Adding to cart… The item has been added
SKU:
PS60005
  • Free Ground Shipping

  • Free Exchanges

  • Safe Payments

  • Competition Grade

Introducing Power Surge - Surge Audio's flagship series of high power amplifiers. These models were designed from the ground up, to be anything other than average. PS Series amplifiers feature a military-grade PCB with the most copper tracing possible, added standoffs for extreme vibration resistance, and overbuilt transformers to withstand the heaviest of abuse.

Cooling is key. The PS Series heatsink was custom tooled to optimize cooling capacity. We made use of thermal modeling to determine the best possible heat dissipation capacity of our heatsink options. Beyond that, we have spaced the mounting feet 1/4" below the heatsink to allow for additional airflow below the backplate of the amplifier.

All PS Series amplifiers include silver plated Tiffany style RCA inputs, four-stage intelligent protection circuitry, and a remote bass knob with clipping, voltage, and temperature indication.

Click HERE for PS Series Instruction Manual



Features:

  • High Efficiency Class D Multi-Channel Architecture
  • Channels 1-4: 2Ω Stable
  • Channel 5: 0.5Ω Stable
  • Channel 1/2 & 3/4 & 5 Clipping Indicators
  • Dual 1/0 Power & Ground Inputs
  • Tiffany-Style RCA Inputs
  • 4-Stage Protection Circuit
  • Wired Remote with Clipping, Voltage, and Temperature Indication



Specifications:

  • Channels 1-4:
  • RMS Power @ 2Ω: 625 Watts x 4 Channels (14.4V)
  • RMS Power @ 4Ω: 400 Watts x 4 Channels (14.4V)
  • RMS Power @ 4Ω (Bridged) : 1,250 Watts x 2 Channels (14.4V)



  • Channel 5:
  • RMS Power @ 1Ω: 3,500 Watts x 4 Channels (14.4V)
  • RMS Power @ 2Ω: 2,500 Watts x 4 Channels (14.4V)
  • RMS Power @ 4Ω: 1,500 Watts x 4 Channels (14.4V)



  • Channels 1-2
    • Frequency Response: 10Hz - 25KHz
    • High Pass Filter: 20Hz - 800Hz
  • Channels 3-4
    • Frequency Response: 10Hz - 25KHz
    • High Pass Filter: 20Hz - 800Hz ( 200Hz - 8KHz , x 10 Multiplier )
    • Low Pass Filter: 50Hz - 800Hz ( 500Hz - 8KHz , x 10 Multiplier )
  • Channel 5
    • Frequency Response: 12Hz - 260Hz
    • Low Pass Filter: 35Hz - 250Hz
    • Subsonic Filter: 10Hz - 50Hz
    • Bass Boost: 0 - 12dB
    • Bass Boost Frequency: 20Hz - 80Hz



  • Input Sensitivity: 6V - 0.2V
  • Signal to Noise Ratio: 88dB <
  • THD @ 4Ω: > 0.1%
  • Fuse Rating: 600A
  • Dimensions: 23.23L x 9.05W x 2.56H



Dyno Results:

  • Subwoofer Channel (Channel 5)
    • Dynamic 0.5 ohm: 8,449 Watts @ 14.28V
    • Certified 0.5 ohm: 4,418 Watts @ 14.30V
    • Dynamic 0.67 ohm: 7,423 Watts @ 14.50V
    • Certified 0.67 ohm: 4,373 Watts @ 14.39V
    • Dynamic 0.8 ohm: 6,491 Watts @ 14.54V
    • Uncertified 0.8 ohm: 4,246 Watts @ 14.26V
    • Certified 0.8 ohm: 4,172 Watts @ 14.46V
    • Dynamic 1 ohm: 5,393 Watts @ 14.66V
    • Uncertified 1 ohm: 3,893 Watts @ 14.34V
    • Certified 1 ohm: 3,807 Watts @ 14.42V
    • Dynamic 2 ohm: 3,134 Watts @ 14.57V
    • Uncertified 2 ohm: 2,733 Watts @ 14.43V
    • Certified 2 ohm: 2,707 Watts @ 14.50V
    • Dynamic 4 ohm: 1,693 Watts @ 14.57V
    • Uncertified 4 ohm: 1,613 Watts @ 14.42V
    • Certified 4 ohm: 1,604 Watts @ 14.47V
  • Channels 1-4
    • Uncertified Bridged 4 ohm: 1,303 Watts x2 @ 14.71V
    • Certified Bridged 4 ohm: 1,310 Watts x2 @ 14.72V
    • Uncertified 2 ohm: 693 Watts x4 @ 14.45V
    • Certified 2 ohm: 697 Watts x4 @ 14.46V
    • Uncertified 4 ohm: 443 Watts x4 @ 14.56V
    • Certified 4 ohm: 445 Watts x4 @ 14.57V

1 Review

  • 5
    Power

    Posted by Benjamin on 10th Dec 2023

    I gotta see this 5th channel at .5 ohms.
